LD26 Van rack for Expert, Jumpy, Vivaro, Scudo & ProAce L2

Art. Nr:26-EJP-L2H1-Y16-R-LD

A van rack with easily accessible drawers for easier work in the Expert, Jumpy, Vivaro, Scudo & ProAce L2.

826 £

Exclude 20 % vat

Product information

Do you need to maximise your Peugeot Expert, Citroën Jumpy, Opel Vivaro, Fiat Scudo & Toyota ProAce L2 with an additional shelf? This is a rack that allows you to maintain the width of the van as the shelf is 260 mm deep. The rack has 3 drawers on ball bearing rails of varying sizes to create different storage options. These can be supplemented with insert kits or drawer inserts to properly organise smaller assortments. The shelf space behind the drawer unit is often enhanced with modular boxes. Distributed load weight in the drawers is 35 kg each. The internal dimensions of the drawers are (mm) W-163, D-387, H-60 and H-130.
The accessories in the picture are not included, but they are of course available for purchase.

The price excludes fitting details. Fitting method is chosen in the next step.
Instructions for assembly are included.

Van racks from Work System are manufactured in Sweden and carefully developed to withstand heavy loads.

End profiles

Work System ends in black anodised aluminium have been carefully developed and tested for several years. All to create the ultimate profile. This has resulted in a very light and strong design with extensive areas of application. Use it for our standard systems, double floors, smart floors, folding shelves or why not something completely customised and unique? With our corner junctions and angles, the possibilities are almost limitless. Products and parts can be fastened directly in the drilled holes with C/C 17.5 mm using our taptite screws, without having to thread the holes beforehand! Parts and products can also be attached to the aluminium profile's grooves, but here our profile's slot nuts are infinitely variable in this application. Perfect for tool boards, for example, that you want to adjust in height according to your particular equipment.
-6063-T6 aluminium material
-15 micrometre thick black anodising
-ACT tested

Tool board

Our systems come with tool boards that increase storage space and possibilities even further. The tool boards are made of 1 mm aluminium with 15 micrometre thick transparent anodising that allows the tool boards to withstand tough environments and conditions while retaining their appearance. Don't lay things loosely on the floor. Save space and time by hanging them on our systems instead! Our tool boards can be fitted with smart accessories, such as:
-Smart boxes for storage of spray cans, bottles, etc. Available in widths of 230mm, 330mm and 1200mm.
-Smartbox glue tube for storage of up to 8 glue tubes.
-Smartbox tube for storage of pipes or larger drills and tools. Available in widths x depths of 50x50mm, 70x70mm and 105x105mm.
-We have a large selection of different hooks to hang everything from cables to tools.
